19mm 3 Way Push Button Switch 2 3 Position with LED Light Rotary Selector FILN

Button Switch DrawingProduct Overview

The FILN 19mm 3 way push button switch (FLCM19-RJ-1-E) is a premium stainless-steel-3-position-rotary-switch designed for advanced industrial control. Unlike standard momentary or latching buttons, this model utilizes a rotary handle to manage 2-position or 3-position circuitry. Featuring a sleek 19mm-metal-selector-switch-led design with a vibrant ring indicator, it is widely used in automation, electrical cabinets, and CNC machinery. With full certifications including ISO9001, CE, VDE, RoHS, SGS, and UL, and an IP65 waterproof rating, this industrial-illuminated-selector-switch-12v ensures reliable performance in harsh environments. As a direct FILN factory product, we offer high-security flcm19-rj-1-e-selector-switch-specification standards with global support.

🛒 Explore Full Range of FILN Push Button Switches →

Quick Specifications

Model Number	FLCM19-RJ-1-E
Mounting Size	19mm
Function Type	Rotary Selector (2-Pos / 3-Pos)
Terminal Config	2-Pos (5-Pin) / 3-Pos (8-Pin)
LED Colors	Red, Green, Yellow, Blue, White
Shell Material	Stainless Steel / Chrome Brass

Performance Parameters

Rated Voltage	12V / 24V (Support up to 250V AC)
Rated Current	5A AC/DC
Insulation Resistance	≥ 1000MΩ
Dielectric Strength	1800V
LED Rated Current	< 20mA

Component Materials

Actuator	304 Stainless Steel / 6063 Aluminum
Shell Sleeve	H59 Brass / Stainless Steel
Pins	H62 Copper Alloy
Base	PA66+GF20% Flame Retardant
Contact	Silver Contact AgCdO12

General Characteristics

Temperature Range	-25°C to +85°C
Protection Level	IP65, IK08
Mechanical Life	500,000 times
Electrical Life	100,000 times

LED Specification

Forward Current	20mA (Typical)
Peak Wavelength	632.2 nm (Red) / 520.7 nm (Green)
Light Intensity	1000 mcd

Key Features

• Rotary Precision: Unlike standard buttons, the rotary handle provides distinct tactile feedback for 3-way-rotary-push-button-switch-wiring.
• Visual Feedback: The 19mm-led-ring-selector-switch-24v offers clear status indication even in dark environments.
• High-Level Protection: IP65 waterproof and IK08 impact resistance ensure longevity in outdoor and industrial settings.
• Versatile Mounting: Simple threaded installation with M19 nut and silicone rubber gasket for a perfect seal.
• Space Efficiency: Compact 8-pin-3-position-push-button-switch design manages complex circuits within a small panel footprint.

Applications

The waterproof-panel-mount-rotary-switch-ip65 is essential for:

• CNC Machinery Mode Selection (Manual/Auto).
• Industrial Control Panels and Electrical Cabinets.
• Marine Dashboard Systems and Automotive Function Control.
• Automation Equipment requiring multi-state logic.

Push Button vs. Rotary Switch

Feature	Standard Push Button	FILN Rotary Selector
Operation	Press (Momentary/Latching)	Rotate (2 or 3 Position)
Circuit Control	Simple On/Off	Multi-circuit Selection
Visual Status	Depends on LED	Physical Handle Position + LED

Installation Guide

1. Drill a 19mm hole in the control panel.
2. Place the rubber gasket onto the switch body.
3. Insert the rotary switch through the hole from the front.
4. Tighten the M19 metal nut from the back to secure the unit.
5. Connect the pins (5-pin for 2-pos, 8-pin for 3-pos) as per the wiring diagram.

Wiring & Pin Configuration

A 5-PIN switch consists of a Common (C), Normally Open (NO), and Normally Closed (NC) terminal. [cite: 1] Use these connections to control whether a device turns on or off when pressed. [cite: 2]

• C (Common): Power input terminal. [cite: 3]
• NO (Normally Open): Connects only when rotated/pressed. [cite: 3]
• NC (Normally Closed): Disconnects when rotated/pressed. [cite: 3]

Factory Direct Supply

FILN offers professional customization for B2B procurement:

• MOQ: 1 Piece Available
• Fast Lead Time & Global Shipping
• Voltage & Wire Length Customization
• Free Samples Available

Request a Free Sample

Official Website: www.filn.com
Contact Email: [email protected]

Frequently Asked Questions (FAQ)

Q1: How many pins does the 3-position switch have?
The 3-position version uses an 8-pin terminal layout to support complex 3 way switch wiring. Q2: Is the LED ring available in multiple voltages?
Yes, our 19mm-led-ring-selector-switch-24v supports 12V and 24V, and can be customized for up to 220V. Q3: Can I get a 5-pin 2-position switch?
Yes, the 2-position rotary selector uses a standard 5-pin configuration (1NO1NC + LED pins). Q4: Is the housing made of real stainless steel?
Yes, the shell is crafted from 304 Stainless Steel for maximum corrosion resistance. Q5: What is the protection rating for this switch?
It is rated IP65, meaning it is dust-tight and protected against water jets. Q6: Can I customize the wire harness length?
Yes, FILN factory provides custom wire lengths and connectors for all 3-way-rotary-push-button-switch-wiring orders. Q7: Does this switch have a momentary function?
No, this model is a rotary selector (fixed position) and does not have momentary action. Q8: What LED colors are available for the 19mm selector?
We offer Red, Green, Yellow, Blue, and White (R/G/Y/B/W). Q9: How do I install this on a panel?
It uses a simple thread-mount system with an M19 nut and a rubber waterproof gasket. Q10: Is there a warranty for industrial use?
Our switches have a mechanical life of 500,000 cycles and carry full CE/UL certifications for industrial safety.
